HR bow shackle - Dia 14 mm

Part #WD-11240

Description

Forged bow shackle in HR stainless steel grade (17,4 PH)
Outstanding working and breaking load
A HR shackle can be up to 60% more resistant than a shackle in 316L stainless stee
WLL: only for industrial applications (lifting i.e…)
CE marking and batch number

Applications

Applications requesting high loads
To be used when ample room is required
Possibility to attach several lines or cables
Do not use for moorring applications

• MaterialsHR 17.4 PH stainless steel grade

• Working load (kg)5120

• WLL (kg)2400

• Breaking load (kg)12000

• Weight (g)364

• A (mm)63

• B (mm)28

• C (mm)14

• D (mm)28

• D diameter (mm)14

• E (mm)13

• H (mm)44

• M (mm)72

HR bow shackle - Dia 16 mm

Part #11247

• MaterialsHR 17.4 PH stainless steel grade

• Working load (kg)6800

• WLL (kg)3800

• Breaking load (kg)19000

• Weight (g)526

• A (mm)70

• B (mm)32

• C (mm)16

• D (mm)32

• D diameter (mm)16

• E (mm)15

• H (mm)50

• M (mm)83
